The Urinary Tract: From Kidney to Bladder

Your kidneys can be producing urine normally, but that urine still has a journey to make before it reaches the toilet, a urinal or a catheter bag. The urinary tract is not simply a set of passive tubes. Urine is collected, moved, stored and then released through a coordinated system of muscle activity and nervous control.

For student nurses, that matters because a change in urine output does not automatically tell you where the problem is. A patient who has not passed urine may be producing less urine, but they may also be producing urine that is not leaving the bladder. A catheter bag that suddenly stops filling may reflect a change in renal perfusion, or it may be a drainage problem. Anatomy helps you work through the possibilities safely rather than jumping to one conclusion.

The route is: nephrons → collecting ducts → calyces → renal pelvis → ureters → bladder → urethra.

From kidney to bladder

Urine is formed within the nephrons and passes through the collecting system of the kidney. From the collecting ducts it drains into the renal calyces and then into the renal pelvis, the funnel-shaped collecting area at the centre of the kidney.

From here, the renal pelvis narrows into the ureter. This is where the job changes. The kidney has produced and collected the urine; the ureter now has to move it towards the bladder.

Each kidney has a ureter, usually around 25 to 30 cm long in an adult. These are not passive drainage tubes. Their walls contain smooth muscle that contracts in coordinated waves called peristalsis, actively propelling urine towards the bladder.

That is an important distinction. Urine does not simply fall down the ureters because of gravity. It can still travel towards the bladder whether the patient is standing, sitting or lying down.

At the lower end, each ureter passes obliquely through the bladder wall before opening into it. As the bladder fills, this arrangement helps compress the section of ureter within the bladder wall and limits urine travelling backwards towards the kidneys.

This becomes clinically useful when you think about obstruction. If a ureter is blocked, for example by a stone, urine can build up above the obstruction and pressure can be transmitted back towards the kidney. The problem is therefore not only pain. Persistent obstruction can interfere with normal urinary drainage and kidney function.

Once urine reaches the bladder, the system changes again. The bladder is a hollow muscular reservoir lined by urothelium, a specialised epithelium that can accommodate stretching as the bladder fills. Its wall contains the detrusor muscle, which is central to bladder emptying.

At the base of the bladder is the trigone, a triangular area marked by the two ureteric openings and the internal opening of the urethra. It is a useful landmark because it links the route in from the kidneys with the route out of the bladder.

How the bladder stores and empties urine

The bladder has to do two opposite jobs well: store urine without leaking, then empty when the time is right.

During storage, the detrusor remains relatively relaxed while the outlet remains closed. As the bladder fills, stretch signals from its wall travel through sensory pathways to the spinal cord and higher centres in the nervous system. That is how bladder filling eventually becomes the conscious sensation that you need to pass urine.

Micturition is the medical term for emptying the bladder. Normal voiding depends on the bladder and outlet changing jobs at roughly the same time.

During storage, sympathetic and somatic pathways help maintain a relaxed bladder and a closed outlet. Somatic control through the pudendal nerve helps keep the external urethral sphincter contracted, contributing to voluntary continence.

When voiding is appropriate, parasympathetic activity increases. The detrusor contracts, resistance at the bladder outlet falls and the external urethral sphincter relaxes. The pontine micturition centre in the brainstem helps coordinate this switch, while higher brain centres allow bladder emptying to be delayed until it is socially and practically appropriate.

You do not need to memorise every nerve pathway to understand the principle:

Storage requires a relaxed bladder and a closed outlet. Emptying requires a contracting bladder and an open outlet.

That simple principle also helps explain why neurological disease or injury can cause very different urinary problems depending on which pathways are affected. Some patients struggle to store urine, some struggle to empty it, and some experience a mixture of both.

Once the bladder contracts and the outlet opens, urine enters the urethra. The female urethra is relatively short and runs from the bladder to the external urethral opening. The male urethra is longer and passes through the prostate and penis before reaching the exterior.

Those anatomical differences matter during urinary catheterisation, but catheterisation is not simply an anatomy exercise. It is an invasive procedure that requires an appropriate indication, aseptic technique, assessed competence and adherence to local policy.

NICE guidance on infection prevention in primary and community care recommends reviewing the need for an indwelling urinary catheter regularly and removing it as soon as it is no longer needed. Where clinically appropriate and practical, intermittent catheterisation may be preferable to a long-term indwelling catheter. In hospital practice, students should also follow their organisation's current catheter policy and local procedures.

Bring it back to the patient

Imagine a post-operative patient who has not passed urine for several hours. Their urine output looks low on the fluid balance chart, but that does not automatically tell you that the kidneys have stopped producing urine.

Work through the pathway. Have they passed urine at all? Do they feel the urge to void? Are they uncomfortable or visibly distended over the lower abdomen? What have they taken in? What has their urine output trend been? Is a bladder scan indicated under local practice? Could they be retaining urine rather than failing to produce it?

Now imagine the patient already has an indwelling catheter and the drainage bag has stopped filling. Again, start with the patient rather than the equipment. Look at the wider clinical picture and the urine-output trend. Check the drainage system for an obvious kink, compression or positioning problem and make sure it is being managed according to local catheter-care policy.

If output remains unexpectedly low, the patient is uncomfortable, the bladder appears distended or you are concerned about obstruction or deterioration, escalate. Do not flush, manipulate, remove or replace a urinary catheter unless you are trained, authorised and working within the local procedure.

If catheter-associated urinary tract infection is suspected, NICE advises obtaining a urine sample before antibiotics where possible. For a patient with a catheter in place, the sample should be taken from the catheter sampling port, if provided, using an aseptic technique rather than from the drainage bag.

This is why the anatomy matters. When urine output changes, think through the whole route. Is urine being produced? Can it travel from the kidney to the bladder? Can the bladder store and then empty it? If a catheter is present, is the drainage system working as expected?

You are not expected to diagnose the cause independently as a student nurse. You are expected to notice the change, assess the patient, check what you safely can, communicate what you have found and escalate appropriately.

A simple way to hold the pathway in your head: the kidney makes it, the renal pelvis collects it, the ureter moves it, the bladder stores it and the urethra lets it out.

Related Bleepbook learning

If you want to take the physiology into clinical assessment, read Urine Output and Oliguria: When Reduced Output Matters.

References

• Lescay, H.A., Jiang, J., Leslie, S.W. et al. Anatomy, Abdomen and Pelvis: Ureter. StatPearls. Available from: NCBI Bookshelf.
• Lanzotti, N.J., Tariq, M.A. and Bolla, S.R. Physiology, Bladder. StatPearls. Available from: NCBI Bookshelf.
• National Institute for Health and Care Excellence. Healthcare-associated infections: prevention and control in primary and community care (CG139). Available from: NICE.
• National Institute for Health and Care Excellence. Urinary tract infection (catheter-associated): antimicrobial prescribing (NG113). Available from: NICE.
